orm Factor
M.2 2280
Interface
PCIe Gen3x4
Performance
256GB —sequential read up to 3500MB/s- write up to 1300MB/s
IOPS: up to 92/240K
512GB —sequential read up to 3500MB/s- write up to 2400MB/s
IOPS: up to 200/256K
1TB —sequential read up to 3500MB/s- write up to 3000MBs
IOPS: up to 200/256K
2TB —sequential read up to 3500MB/s- write up to 3000MBs
IOPS: up to 300/256K
Operating Temperature
0°C to 70°C (32°F to 158°F)
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
Dimension (L x W x H)
80 mm x 22 mm x 2.25 mm / 3.15” x 0.87” x 0.09”
Weight
9g
Warranty
5 year limited warranty
Shock Resistant
1500 G- duration 0.5ms- Half Sine Wave
Vibration Resistant
10~2000Hz- 1.5mm- 20 G- 1 Oct/min- 30min/axis(X-Y-Z)
TBW
2TB:1000- 1 TB: 500 TB- 512 GB: 250 TB-- 256 GB: 125 TB
DWPD
1 TB: 0.44- 512 GB: 0.44- 256 GB: 0.44
NAND flash
3D TLC
MTBF
1-500-000 Hours
